If you need to take an even closer look: With a resolution of up to 4,800 dpi, you can even spot the last grain of dust. The specially developed LED lighting, with 2 double rows and 308 LEDs, provides shadow-free illumination. 1,600 candela light intensity makes the lasered inscriptions on the ICs virtually glow.
Features
Technical details
Dimensions
693 x 504 x 323 (BxTxH)
Weight
30 kg
Image unit
CCD line scan camera (7,020 pixels/line)
Max. resolution
1,200 dpi, with -/HR up to 4,800 dpi
Effective pixels
71,6 Megapixel
Max. image size
430 x 320 mm
Max. component size
• 510 x 349 mm • 600 x 390 mm (PCB)
Throughput height
• 50 mm (SMD/mixed assembly) • 60 mm (THT)
Scan speed
• 3,8 ms/line (color) • 1,3 ms/line (black and white)
Always the perfect solution for your application. Simply expand Quins Easy and Easy+ with the modules you need. Visual inspection and first article inspection paired with tracking, repair, statistics and data control. Easy.
